K-Rain RPS624 Outdoor 24 Station Irrigation Controller 240V AC

Description

Low energy, high-output toroidal transformer.

The latest in micro-processor technology. Lockable and waterproof case designed for outdoor residential and light commercial applications.

Advanced features include current sensing and station skip with fault indication, and a real-time clock maintains time through power outages.
24 station 220V internal transformer

Features & Benefits

• Wifi Enabled - Syncs with Wifi for functionality through a smartphone, tablet, or web browser, with remote access and alerts.
• 6 Fully Independent Programs - Up to 4 separate start times per program, with a maximum of 24 starts per day.
• Permanent Memory - Saves programs during power outages.
• 7 Day Watering Cycle - Individual day selection, odd/even date selection, or interval watering.
• Rain Sensor Ready - Allows programming of individual station(s) operation to be controlled by a sensor.
• Rain Off - Suspends watering during winter while retaining the time and programmed information.
• Flexible Manual Operation - Choose from automatic, semi-automatic, and single station manual modes.
• System Test Feature - Tests the system for functionality.
• Water Conservative - Quick adjustment of watering durations in 10% increments, from OFF to 200%.
• Master Valve/Pump Start - Controls the master valve or pump start.
• Second Programmable Pump - Available for dual water supply, fertigation, or filtration control.
• Large Blue and White Backlit LCD - Easy to read, with a “No AC” indicator on the LCD when power is out.
• Current Sensing - On individual stations with a faulty station skip feature.
• Low Energy Micro-processor - Ensures long battery life.
• Permanent Real-time Clock - Maintained by a 3V battery and a Toroidal high capacity transformer.
• Outdoor Case - Lockable and waterproof.
• Audio Feedback - Provides audio feedback on key presses and alarms.

Specifications

Operating Specifications

• Station run times 1 minute to 12 hours and 59 minutes
• Number of programs 6
• Number of automatic start times 4 per program
• Program numbering schedules:
  Odd (odd calendar days)
  Even (even calendar days)
  Custom (days of the week)
  Interval (1-7 days)

Electrical Specifications

• Power Input 220V AC 24V AC 1.25 Amp rated Toroidal transformer
• Power Output 24V AC 0.75

Optional Extras

• 3208-HRS – Hardwired Rain Sensor

Dimensions

• Height 22.8cm
• Width 23.5cm
• Depth 8.9cm
